Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine  for Sale

Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine for Sale

  • High Light

    jaw stone crusher

    ,

    rock crusher machine

  • Model
    PE/PEX Series Jaw Crusher
  • Capacity
    1 - 500 (t/h)
  • Condition
    New
  • After-sales Service Provided
    Engineers Available To Service Machinery Overseas
  • Warranty
    12 Months
  • Material
    Stone Crushing
  • Motor Type
    AC Motor
  • Spare Parts
    Supply All Using Life
  • Voltage
    220V/380V/440
  • Processing Materials
    Various Rocks, Ores, Limestone, Construction Waste, Etc., Used In The Crushing Of Bulk Materials In Metallurgy, Building Materials, Mining, Highway, Mineral Processing And Other Industries
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    PCH-0402--PCH-1221
  • Minimum Order Quantity
    1 set
  • Price
    USD 8000-20000 set
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    100 Set / Sets per Month

Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine for Sale

Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine for Sale


PCH series Jaw crusher will be the fresh generation involving jaw crusher together with optimized along with developed design and style, that's according to ingesting the global sophisticated technological innovation. In contrast to your equivalent-size crusher, this is greater than together with greater potential, bigger crushing ratio, decrease operating charge, and also the helpful, stable and trustworthy function. PCH series jaw crusher will be the favored product or service for primary crushing.





Processing materials: various rocks, ores, limestone, construction waste, etc., used in the crushing of bulk materials in metallurgy, building materials, mining, highway, mineral processing and other industries



Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine  for Sale 0



Stone Crush Plant Product Features
1. Recently PCH series crushing chamber: the actual crushing capability will probably be extremely greater, the item dimensions is going to be smaller and also crushing overall performance will improve.


2. The actual Style sheet might be fine-tuned for you to perhaps more compact, that makes the product dimension smaller.


3. The production opening shall be fine-tuned by the hydraulic tube in addition to wedges, that is managed ideally as well as successfully.


4. To meet the several wants there's two diverse installment style regarding motor: it could be included set up together with the crusher body or even attached to the floor.


5. Your included construction associated with main displaying property and also swing chin makes all the transport far more less difficult and the set up easier.


6. The best transferring trail as well as the counterweight harmony cuts down on energetic weight, vibration plethora as well as noises, and also steady function.


7. Intelligent framework,steady along with trustworthy,basic and convenient servicing.


8. The toggle plate as well as the golf swing jaw bone dish possess the horizontal deviation purpose.


9. Compared with the standard form of crushing holding chamber, the newest form of crushing chamber will make the throughput potential elevated through 15~20%.



Stone Crush Plant Jaw Crusher / Small Jaw Crusher Machine  for Sale 1


Technical Parameters:



Model

Feed Inlet Size

(mm)

Max Feed
Size (mm)

Discharge Size

Range (mm)

Capacity
(m3/h )
Motor Power
(kw)
PE-250x400 250x400 210 20-60 3-13 15
PE-400x600 400x600 340 40-100 10-35 30
PE-500x750 500x750 425 50-100 25-60 55
PE-600x900 600x900 500 65-180 30-85 55-75
PE-750x1060 750x1060 630 80-180 72-150 90-110
PE-800x1060 800x1060 680 100-200 85-143 90-110
PE-870x1060 870x1060 750 170-270 145-235 90-110
PE-900x1060 900x1060 780 200-290 170-250 90-110
PE-900x1200 900x1200 780 95-255 100-240 110-132
PE-1000x1200 1000x1200 850 195-280 190-275 110-132
PE-1200x1500 1200x1500 1020 150-300 250-500 160
PEX-150x500 150x500 120 10-40 3-15 11
PEX-150x750 150x750 120 10-40 5-16 18.5
PEX-250x750 250x750 210 15-50 8-35 30
PEX-250x1000 250x1000 210 15-50 13-45 37
PEX-250x1200 250x1200 210 15-50 13-50 37
PEX-300x1300 300x1300 250 15-50 20-60 75
