25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space

25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space

  • High Light

    Copper Ore Continouos Ball Mill Grinder

    ,

    25t/H Continouos Ball Mill Grinder

    ,

    Calcium Carbonate Ball Mill Grinder

  • Product Name
    Continouos Ball Mill
  • Condition
    New
  • After-sales Service Provided
    Engineers Available To Service Machinery Overseas
  • Warranty
    12 Months
  • Capacity
    0.8-25t/h
  • Material
    Cement, Iron Ore, Copper Ore
  • Motor Type
    AC Motor
  • Onsite Service
    Supply
  • Voltage
    220V/380V/440
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    MQG900X1800,MQG3000x9000
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    80 Set / Sets per Month

25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space

Cement Continouos Ball Mill From China / Batch Ball Mill for Sale



Introduction:

In the continuous type Ball Mill, the material is being fed from the one end through its hollow shaft, while the crushed material comes out from the hollow shaft, at the other end. Usually continuous Mills are used when the production rate is required to be high.



Specially designed for :Cement, Iron Ore, Copper Ore, Alumina, Cement, Calcium Carbonate, Bauxite, Calcium Carbide, Calcium Oxide, Ceramic, Refractory, Slurry, Coconut shell, Carbon industries etc.



25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space 0



Our Advantage:

1. Energy saving and Long working life: Traditional sliding bearings are replaced by double row roller bearings in small and medium size ball mill to reduce energy consuming, new endurable wearing parts to increase service life of vulnerable parts.

2. Big crushing ratio and High ore particle fineness: The intrinsic grille pattern forcing evacuation is instead by over fall pattern controlling one. This can improve the milling of the granule and the quantity dealt.

3. Simple structure and convenient maintenance: Ball Mill changes the complicated grinding mill structure. We design the body and chassis integration which makes it easy to place the machine on the ground. Three meters of the ball machine above is especially configured with jack-up devices for easy maintenance.

4. Good corrosion resistance and Runs steadily and efficiently: The rotary rack wheel uses casting gear hobbing and inside the cylinder there is wear-resisting lining board which has fine abrasion performance. This ball mill has stable operation and reliable performance.

5. Easy installation Adjustment, and operation and High technology: Low speed driving unit with lifting device; Large ball mills adopt pitot pressure or hydrostatic bearings.



25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space 1



Technical Specifications:



model cylinder rev(r/min) grind media weight (t) feeding size(mm) output size(mm)

output

(t/h)

motor
type power
MQG900X1800 38 1.8 ≦25 0.074-.06 0.8-1 Y255M-8 22
MQG900X3000 37.4 2.7 ≦25 0.074-0.3 0.8 Y225M-6 30
MQG1200x2400 32 4.8 ≦25 0.074-.06 1.5-2 Y280M-8 45
MQG1200X4500 30 5.2 ≦25 0.074-.06 1.5 Y280M-6 55
MQG1500x4500 28.8 10 ≦25 0.074-0.4 3-4 JR126-8 110
MQG1500x5700 28.8 12 ≦25 0.074-0.4 3-5 JR127-8 130
MQG1500x6400 28.8 13 ≦25 0.074-0.4 3-5 JR127-8 130
MQG1830x5400 24.5 15 ≦25 0.074-0.4 5-7 JR137-8 210
MQG18306400 24.5 19 ≦25 0.074-0.4 5-7 JR137-8 210
MQG1830x7000 24.5 20 ≦25 0.074-0.4 6-8 JR138-8 245
MQG2200x7000 21.6 30 ≦25 0.074-0.8 8-10 JR158-8 380
MQG2200x9000 21.4 34 ≦25 0.074-0.8 8-10 JR1510-8 475
MQG2400x7000 20.4 36 ≦25 0.074-0.8 10-14 JR1510-8 475
MQG2400x8000 20.4 42 ≦25 0.074-0.8 10-14 YR630-8 560
MQG2600x8000 19.6 52 ≦25 0.074-0.8 16-20 JR1512-8 630
MQG3000x9000 18.3 78 ≦25 0.074-0.8 20-25 YR1000-8/1180 1000

25t/H Copper Ore Continouos Ball Mill Grinder Little Floor Space 2
