Silica Sand Slurry Continuous Ball Mill For Building Material Chemical Industry
Product Details:
| Place of Origin: | china |
| Brand Name: | zk |
| Certification: | iso,ce |
| Model Number: | MQZ1224-MQZ3660 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | MEET THE SHIPPMENT REQUIRMENTS |
| Delivery Time: | 30 DAYS |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 15 PER MONTH |
|
Detail Information |
|||
| Name: | Silica Sand / Slurry Ball Mill | Feature: | Energy Saving |
|---|---|---|---|
| Model: | MQZ1224-MQZ3660 | Capacity: | 0.5-200(t/h) |
| Feed Size: | 0-30(mm) | Output Size: | 0.05-0.45(mm) |
| Shipping Port: | Shanghai, Qingdao, Tianjin | Voltage: | Local Voltage |
| Installation: | Under Supervision Of Our Engineer | Warranty: | 12 Months |
| High Light: | Slurry Continuous Ball Mill,200T/H Continuous Ball Mill,30mm Feed Continuous Ball Mill |
||
Product Description
Silica Sand / Slurry Ball Mill Energy Saving For Building Material Chemical Industry
Silica Sand Ball Mill Introduction:
Ball mill is mainly used for grinding in mining (metallic minerals and non-metallic minerals), cement, refractories, chemical, power plant, aluminum, building material, glass, ceramic, steel slag and fly ash, ect. It follows more crushing and less grinding principle to save energy. The feed size to ball mill shall be smaller than 25mm, the output size can be adjusted by revising steel balls ratio.
Applied Materials:
Copper, magnetite, molybdenite, zinc ore, iron ore, gold, hematite, fluorspar, lead & zinc, manganese, tungsten, marble, granite, slag, cement, limestone, clinker, coal etc
Silica Sand Ball Mill Application:
1. Liner of ball mill is made of high-quality wear resistant material with high strength, wear resistance and long working life.
2. Product fineness is adjustable, uniform and high qualified.Widely used in powder-making production line
3. Large capacity and crushing ratio, good sealing performance. It can be adapted to different working conditions.
4. High grinding efficiency, low energy consumption, energy-saving and high capacity, productive and cost effective. Can grind various ores and other materials with dry type and wet type
5. There are two ways of grinding: the dry process and the wet process.
6. It can be divided into tabular type and flowing type according to different forms of discharging material.
Silica Sand Ball Mill Specifications:
| Model |
Drum Size (m) |
Speed (r/min) |
Ball Weigh(t) |
Feed Size (mm) |
Output Size (mm) |
Capacity (t/h) |
Power (kW) |
| MQZ1224 | 1.2X2.4 | 31 | 4.8 | 0-20 | 0.07-0.6 | 0.4-6.8 | 37 |
| MQZ1245 | 1.2X4.5 | 31 | 5.2 | 0-20 | 0.07-0.6 | 1.6-12 | 45 |
| MQZ1530 | 1.5X3.0 | 27.5 | 8.1 | 0-25 | 0.07-0.4 | 2.9-16.5 | 65 |
| MQZ1557 | 1.5X5.7 | 29.2 | 15 | 0-25 | 0.07-0.4 | 4-25 | 95 |
| MQZ1645 | 1.6X4.5 | 27.5 | 14 | 0-25 | 0.07-0.4 | 4-24 | 95 |
| MQZ1836 | 1.8X3.6 | 23.9 | 11 | 0-25 | 0.07-0.4 | 8-40 | 132 |
| MQZ1864 | 1.6X6.4 | 23.9 | 18.5 | 0-25 | 0.07-0.4 | 8-60 | 155 |
| MQZ2130 | 2.1X3.0 | 23.8 | 19.8 | 0-25 | 0.07-0.4 | 6.5-36 | 155 |
| MQZ2136 | 2.1X3.6 | 23.8 | 27 | 0-25 | 0.07-0.4 | 8-61 | 155 |
| MQZ2265 | 2.2X6.5 | 21.6 | 28 | 0-25 | 0.07-0.4 | 8-35 | 210 |
| MQZ2430 | 2.4X3.0 | 22 | 22.5 | 0-25 | 0.07-0.4 | 7-92 | 210 |
| MQZ2436 | 2.4X3.6 | 22 | 28 | 0-25 | 0.07-0.4 | 7-95 | 210 |
| MQZ2465 | 2.4X6.5 | 22 | 36 | 0-25 | 0.07-0.4 | 7-110 | 260 |
| MQZ2736 | 2.7X3.6 | 21.9 | 39 | 0-25 | 0.07-0.4 | 13-140 | 310 |
| MQZ2745 | 2.7X4.5 | 21.9 | 43 | 0-25 | 0.07-0.4 | 13-150 | 320 |
| MQZ2836 | 2.8X3.6 | 20 | 42 | 0-25 | 0.07-0.4 | 15-140 | 310 |
| MQZ3060 | 3.0X6.0 | 19 | 70 | 0-25 | 0.07-0.4 | 100-145 | 630 |
| MQZ3245 | 3.2X4.5 | 18.6 | 65 | 0-25 | 0.07-0.4 | 100-145 | 630 |
| MQZ3260 | 3.2X6.0 | 18.6 | 86 | 0-25 | 0.07-0.4 | 120-150 | 800 |
| MQZ3645 | 3.6X4.5 | 17.8 | 90 | 0-25 | 0.07-0.4 | 120-220 | 1000 |
| MQZ3660 | 3.6X6.0 | 17.8 | 120 | 0-25 | 0.07-0.4 | 50-230 | 1250 |
