1000-20000 t/a Lithium Carbonate Production Line Extraction from Lithium Carbonate

1000-20000 t/a Lithium Carbonate Production Line Extraction from Lithium Carbonate

Place of Origin:

China

Brand Name:

ZK

Certification:

CE ISO Certification

Model Number:

Rotary Kiln Ø2.2×38m-Ø4.3×64m

Contact Us
Request A Quote
Product Details
Main Equipment:
Lithium Carbonate Rotary Kiln, Ball Mill, Cooler, Crusher Etc
Product Name:
120-800t/d Lithium Carbonate Production Line Machines
Rotary Kiln Model:
Ø2.2×38m-Ø4.3×64m
Production Capacity:
120-800t/d
Final Product:
Lithium Carbonate
Product Shelf Life:
2 Years
Product Packaging:
Standard Export Packaging
Raw Material:
Lepidolite, Spodumene, Lithium Ore Etc
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 8000-12,000,000
Packaging Details
Export standard container or as customers' requirements
Delivery Time
3 months
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100 Set / Sets per Month
Product Description

Product Description:

Our company has configured a production line for roasting and acidizing lithium ore with lepidolite, spodumene and other raw materials which has excellent product performance, stable production condition and easy operation. The users of our product have given positive recognition to our product.

Moreover, we use wireless temperature monitoring system and remote intelligent variable speed kiln condition control system in kiln which makes it easier for the production personnel to adjust the kiln condition in real time.

The conversion rate of the raw material crystal is high, the acidification is complete and the lithium leaching rate and lithium recovery rate are 15% higher than the traditional process.



1000-20000 t/a Lithium Carbonate Production Line Extraction from Lithium Carbonate 0

Features:

The production line is easy to operate and has very stable performance. To make sure the parameters are more accurately controlled, a wireless temperature measurement and monitoring system is installed to the kiln. This not only helps elevate the efficiency of the overall progress, but also strengthens the waste heat recovery, leading to a good energy saving effect. Additionally, the new dust removal device we have installed has sufficient dust removal effects and maintains a relatively low construction cost.



Technical Parameters:

Spodumene as Raw Material (Without Production of Other Products )

Final Products Annual Output(t/a) Spodumene Amount(t/h) Main Equipment Model
Conversion Process Acidification Process Ball Mill
Lithium LiCO3 5000 5-6 Roasting Kiln:φ2.8×50m; Cooler: φ2.6×40m Acidification Kiln:φ2.8×50m; Cooler: φ2.4×35m φ1.83×6.4m
Lithium LiCO3 10000 10-12 Roasting Kiln:φ3.5×60m; Cooler: φ2.4×40m Acidification Kiln:φ3.5×50m; Cooler: φ2.4×40m φ2.4×8m

Lepidolite as Raw Material

Final Product Annual Output of Lithium(t/a) Amount of Mixed Raw Materials (about 60% of Lepidolite) (t/h) Main Equipment Model
Rotary Kiln Cooler Ball Mill
Lithium LiCO3 3000 15-18 φ3.5×60m φ2.5×23m φ1.83×6.4m
Lithium LiCO3 5000 25-30 φ4.2×72m φ3×45m φ3.2×13m

1. Main equipment: Acidification mixer, rotary kiln, rotary cooler, Acidification kiln, raw ball mill, bag type dust collector and fan.

2. Rotary kiln diameter: 1.5-4.5m.

3. Calcination temperature: ~1250℃

4. Acidification temperature: ~350℃

5. The fuel of calcination:Natural gas, coal dust and coal gas

Applications:

This application is suitable for producing lepidolite and spodumene raw materials through a series of processes such as roasting, acidification and cooling.

Roasting is the process of heating a material in order to break down its chemical structure and prepare it for further processing. Acidification involves adding an acid to the material, often to help it interact with other chemicals in the mixture. And cooling is used to bring the temperature of the material back to a suitable level for further use.

In summary, this application is suitable for producing lepidolite and spodumene raw materials through the three steps of roasting, acidification and cooling.



Support and Services:

We provide comprehensive technical support and service for our new Lithium Carbonate Production Line. Our experienced team of engineers and technicians are ready to answer any questions you may have and provide you with the best technical solutions for your production line.

We also offer ongoing maintenance and support, helping to keep your production line running smoothly and efficiently. Our service team is available 24/7 and can be contacted via phone, email or online chat. We offer quick response times and always strive to provide the best possible customer service.

In addition, we provide parts and components for your Lithium Carbonate Production Line. We supply only high-quality parts that meet the highest standards, ensuring that your production line remains reliable and cost-effective. Our parts are also backed by a comprehensive warranty.

At our company, we are committed to providing the best technical support and service for your Lithium Carbonate Production Line. If you have any questions or concerns, please do not hesitate to contact us.



Packing and Shipping:

Packaging and Shipping of Lithium Carbonate Production Line

The Lithium Carbonate Production Line is packed with a purpose-built wooden crate and strapped securely. The crate is reinforced with industrial-grade foam to ensure product safety during transit.
