Local voltage rotary kiln calcination Durable And Simple Maintenance

Local voltage rotary kiln calcination Durable And Simple Maintenance

  • High Light

    solid waste Rotary Kiln Calcination

    ,

    ISO Rotary Kiln Calcination

    ,

    Single side gear drive Calcination Equipment

  • Product Name
    Industrial Waste Incineration Complete
  • After Sale Service
    Engineers Available To Service Machinery Overseas
  • Model
    1.6x32m-4.7x72m
  • Material
    Sludge Waste, Municipal Waste
  • Voltage
    Local Voltage
  • Motor Type
    AC Motor
  • Warranty
    1 Year
  • After Warranty
    Online Support
  • Marketing Type
    Ordinary Product
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    1.6x32m-4.7x72m

Local voltage rotary kiln calcination Durable And Simple Maintenance

Rotary Kiln Incinerator Introduction:
Rotary incinerator is a widely used incineration equipment in the field of international industrial waste treatment, its market share in the field of industrial waste incineration is really high, As a specific area for burning hazardous wastes , the rotary incinerator has wide adaptability to complex industrial waste and medical waste, and it’s stable and convenient to operate, of course, the equipment maintenance is simple, and so on. Therefore, it is the most widely used in the field of international hazardous waste incineration. It is a reliable and effective means to realize the harmless, reduction and recycling of wastes.



【Applicable materials】

Industrial comprehensive hazardous waste, medical waste, petroleum, chemical, pesticide and other industries of various solid waste, waste liquid, waste gas. Municipal domestic waste, etc.



Advantage:

Low cost: high temperature material contacts refractory. Easy to change lining
The drive mechanism is simple: the drive mechanism is inside the kiln shell. Equipment maintenance is convenient.
To ensure no leakage of harmful gases: good sealing measures and negative pressure in the furnace.
Convenient operation and maintenance: high equipment operation rate. The annual operating rate is generally 90%
Incineration adaptability: solid waste, liquid, colloid and gas can be incinerated at the same time
High heat utilization rate: the material is stirred forward. Three heat transfer modes coexist in one furnace
Combined with patented technology: the traditional secondary combustion chamber has evolved into a secondary combustion furnace. Increases ash burn rate. Improve the combustion efficiency of the rotary kiln. At the same time, it has the functions of normal temperature slag discharge, slag breaking, air lock and so on.



Specifications:



Hazardous waste rotary kiln for waste incinerationφ2.6m*13.2 technical parameter.
Inner diameter of shell 2600mm Shell length 13200mm
Downstream arrangement, that is, the direction of material flow is consistent with the direction of smoke flow, the angle of the kiln body is 1.5 degrees.
Variable frequency speed control of rotary kiln 0.1-2.2r/min
Drive mode Single side gear drive
Main Motor 30kw
Kiln temperature:850-1200 degree Surface temperature of kiln shell: 180 degree
Expansion mode Linear free expansion at both ends
Total equipment weight approx. 54.5t
★ Customized waste incineration rotary kiln can be provided according to the customers' different industries



Rotary Kiln Incinerator Working Principle:
Rotary Kiln Incinerator can deal with solid and liquid waste simultaneously, solid waste is sent into rotary kiln by special conveying equipment, liquid waste is sprayed into the feed end of the Rotary Kiln Incinerator body by means of an efficient atomizing device, the waste in the rotary kiln should experience the process of water evaporation, volatilization analysis, ignition and combustion process, The ash portion is discharged from the bottom of the second combustion chamber, the generated flue gas enters the second combustion chamber, blended with two combustion air in the second compartment, complete combustion of flue gas, achieve exhaust safety standards discharge.
