Chromite Ore Magnetic Separator Machine Energy Saving Easy Operation

Chromite Ore Magnetic Separator Machine Energy Saving Easy Operation

magnetic drum separator

iron ore magnetic separator

Place of Origin:

China

Brand Name:

ZK

Certification:

ISO,CE

Model Number:

Magnetic separator

Contact Us
Request A Quote
Product Details
Capaicty:
10-180 (t/h)
Model:
CTB6012,CTB1230
Shell Dia:
600-1200 (mm)
Shell Length:
1200-3000 (mm)
Type:
Wet And Dry
Place Of Origin:
Henan, China
Dimension(L*W*H):
Customer Request
Installation:
Under Our Engineer's Guide
Design:
By Our Professional Engineer
Condition:
New
Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
Meet the shippment requirments
Delivery Time
30days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
10 per month
Product Description



Chromite Ore Magnetic Separator Machine Energy Saving Easy Operation



1. Magnetic separator introduction:
The iron ore dry magnetic separator is a piece of mineral processing equipment used to recover ferromagnetic materials. It is fit for processing fine, feebly magnetic materials, such as magnetite, pyrrhotite, ilmenite and other materials. In recent years, it can also be used in removing the magnetic minerals from coal, non-metallic minerals, building materials and more.jiangtai iron ore dry magnetic separator is a kind of permanent magnetic drum magnetic separator. Three types of tanks including concurrent flow tank, backflow tank and semi-backflow tank are available to suit different materials and process.



Chromite Ore Magnetic Separator Machine Energy Saving Easy Operation 0


2.Working Principle:
Since the magnetization coefficient of various minerals is different, so under the same magnetic force, strong magnetic materials will get stuck onto the surface of the shell, thus separating from the materials that can not be attracted


3. Features :
1. Reasonable structure, easy installation and operation,
2. Applicable to both wet and dry process
3. Permanent magnetic shell, the magnetic intensity on the shell surface can be designed according to actual application, with strong processing capacity and low maintenance cost.

Model

Drum Dia

mm

Drum Length

mm

Rotate Speed r/min Feed Size
mm
Capacity
t/h
Power
Kw
CTB6012 600 1200 <35 2-0 10-20 1.5
CTB6018 600 1800 <35 2-0 15-30 2.2
CTB7518 750 1800 <35 2-0 20-45 2.2
CTB9018 900 1800 <35 3-0 40-60 3
CTB9021 900 2100 <35 3-0 45-60 3
CTB9024 900 2400 <28 3-0 45-70 4
CTB1018 1050 1800 <20 3-0 50-75 5.5
CTB1021 1050 2100 <20 3-0 50-100 5.5
CTB1024 1050 2400 <20 3-0 60-120 5.5
CTB1218 1200 1800 <18 3-0 80-140 5.5
CTB1224 1200 2400 <18 3-0 85-180 7.5
CTB1230 1200 3000 <18 3-0 100-180 7.5
