High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator

High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator

  • High Light

    magnetic drum separator

    ,

    iron ore magnetic separator

  • Capaicty(t/h)
    15-170
  • Model
    CTB6012-CTB1230
  • Shell Dia(mm)
    600-1200
  • Shell Length(mm)
    1200-3000
  • Application
    Ore Dressing, Recycling, Ceramic, Chemical Industry
  • Place Of Origin
    Henan, China
  • Dimension(L*W*H)
    Customer Request
  • Installation
    Under Our Engineer's Guide
  • Spare Parts
    Supply All Using Life
  • Condition
    New
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    ISO, CE
  • Model Number
    Magnetic separator
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Meet the shippment requirments
  • Delivery Time
    30days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 per month

High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator



High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator



Magnetic separator introduction:
The iron ore dry magnetic separator is a piece of mineral processing equipment used to recover ferromagnetic materials. It is fit for processing fine, feebly magnetic materials, such as magnetite, pyrrhotite, ilmenite and other materials. In recent years, it can also be used in removing the magnetic minerals from coal, non-metallic minerals, building materials and more.jiangtai iron ore dry magnetic separator is a kind of permanent magnetic drum magnetic separator. Three types of tanks including concurrent flow tank, backflow tank and semi-backflow tank are available to suit different materials and process.



High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator 0


Working Principle:
Since the magnetization coefficient of various minerals is different, so under the same magnetic force, strong magnetic materials will get stuck onto the surface of the shell, thus separating from the materials that can not be attracted


High Capacity Magnetic Separator Machine , Chromite Ore Magnetic Drum Separator 1



OUR ADVANTAGES
1. The Magnetic separator can be down-flow, semi-countercurrent, countercurrent type according to customer’s need. There are different magnetic strength for each type.
2. Easy operation and maintenance, simple structure, stable and reliable performance
3. The advantage of magnetic separator is simple structure,large process capacity, easy operation and maintenance and so on.



Features :
1. Reasonable structure, easy installation and operation,
2. Applicable to both wet and dry process
3. Permanent magnetic shell, the magnetic intensity on the shell surface can be designed according to actual application, with strong processing capacity and low maintenance cost.



Parameter:


Model

DrumDia

mm

DrumLength

mm

Rotate Speed r/min Feed Size
mm
Capacity
t/h
Power
Kw
CTB6012 600 1200 <35 2-0 10-20 1.5
CTB6018 600 1800 <35 2-0 15-30 2.2
CTB7518 750 1800 <35 2-0 20-45 2.2
CTB9018 900 1800 <35 3-0 40-60 3
CTB9021 900 2100 <35 3-0 45-60 3
CTB9024 900 2400 <28 3-0 45-70 4
CTB1018 1050 1800 <20 3-0 50-75 5.5
CTB1021 1050 2100 <20 3-0 50-100 5.5
CTB1024 1050 2400 <20 3-0 60-120 5.5
CTB1218 1200 1800 <18 3-0 80-140 5.5
CTB1224 1200 2400 <18 3-0 85-180 7.5
CTB1230 1200 3000 <18 3-0 100-180 7.5
