Place of Origin:
China
Brand Name:
ZK
Certification:
CE ISO Certification
Model Number:
linear vibrating screen
Mining linear vibrating screen for coal powder, sand vibrating sieve machine
Introduction:
ZK series linear vibrating screen is based on the needs of China's production in the digestion and absorption shaker from abroad on the basis of summing up of our years of research experience in the design and use, combined with the national conditions , China developed this new series of vibrating screen.
Through years of practice, that the series of machine has to deal with a large amount of technical parameters of a reasonable structural strength, high stiffness, serialization, generic, and a high degree of standardization, smooth and reliable operation, low noise, maintenance overhaul to facilitate a series of advantages
Linear vibrating screen can screen and classify powder and granular material. It is applied widely in plastics, abrasives, chemicals, pharmaceuticals, building materials, food, carbon, fertilizer and other industries.
Metal Vibrating Screen Structure:
Linear vibration sieve using vibration motor as vibration source, the materials is thrown up on the screen, at the same time for linear motion, the material feeding from the feeder evenly into the screen, screen material, produced a number of specifications through multi-layer screen material, separately from the respective outlet.
Our Advantages of Industry Vibrating Screening Machine:
1. Sieve machine design, ingenious and easy to assemble, one person can operate the screening machine.
2. Independent and other related brand manufacturers, compared with a larger screen area and high efficiency of processing capacity.
3. Unique screen structure design, convenient and fast change screen (only 3 to 5 minutes), in addition, this design allows the use of a variety of screen (nylon, special dragon, PP nets).
4. The parent network to fully support the fine mesh, so fine mesh scored a longer life, and reduce the supplies of fine mesh, the production process and the long time can reduce a lot of cost.
Linear Vibrating Screen Specifications:
| Model | Sieve Specifi- cations |
Sieve layer | Mesh size |
Feeding size | Cap-acity | Motor Power | Total Weight |
Vibr-ating frequ-ency | Double ampl- itude |
Sieve obliq-uity |
Dimensions |
| (L*W)(mm) | Layer | mm | mm | (t/h) | kw | kg | (Hz) | (mm) | o | L*W*H(mm) | |
| ZSG1237 | 3700*1200 | 1 | 4-50 | <=200 | 10-100 | 5.5*2 | 2250 | 16 | 6-8 | 15 | 3800*2050*1920 |
| 2ZSG1237 | 3700*1200 | 2 | 4-50 | <=200 | 10-100 | 5.5*2 | 3345 | 16 | 6-8 | 15 | 3800*2050*2200 |
| ZSG1443 | 4300*1400 | 1 | 4-50 | <=200 | 10-150 | 5.5*2 | 4100 | 16 | 6-8 | 15 | 4500*3040*2500 |
| 2ZSG1443 | 4300*1400 | 2 | 4-50 | <=200 | 10-150 | 5.5*2 | 4900 | 16 | 6-8 | 15 | 4500*3040*2700 |
| 3ZSG1443 | 4300*1400 | 3 | 4-50 | <=200 | 10-150 | 5.5*2 | 5870 | 16 | 6-8 | 15 | 4500*3040*2820 |
| 2ZSG1548 | 4800*1500 | 2 | 5-50 | <=200 | 15-200 | 7.5*2 | 5836 | 16 | 8-10 | 15 | 4800*3140*2814 |
| 3ZSG1548 | 4800*1500 | 3 | 5-50 | <=200 | 15-200 | 7.5*2 | 6900 | 16 | 8-10 | 15 | 4799*3140*3014 |
| 2ZSG1848 | 4800*1800 | 2 | 5-50 | <=300 | 50-500 | 7.5*2 | 6489 | 16 | 8-10 | 15 | 4799*3440*2814 |
| 3ZSG1848 | 4800*1800 | 3 | 5-50 | <=300 | 50-500 | 7.5*2 | 7750 | 16 | 8-10 | 15 | 4799*3440*3014 |
| 4ZSG1848 | 4800*1800 | 4 | 5-50 | <=200 | 50-500 | 11*2 | 8300 | 16 | 8-10 | 15 | 4799*3440*3503 |
| 2ZSG1860 | 6000*1800 | 2 | 5-150 | <=300 | 80-600 | 11*2 | 9950 | 16 | 8-10 | 15 | 6000*3440*3326 |
