380V Activated Lime Rotary Kiln Easy Maintenance And Low Pollution

380V Activated Lime Rotary Kiln Easy Maintenance And Low Pollution

  • High Light

    Low Pollution Activated Lime Rotary Kiln

    ,

    380V Activated Lime Rotary Kiln

  • Capcity
    50-1000TPD
  • Main Equipment
    Rotary Kiln, Preheater, Ball Mill, Bag Filter Etc
  • Application
    Active Lime / Quicklime / Hydrated Lime Production Plant
  • After Sale Service
    Engineers Available To Service Machinery Overseas
  • Installation
    Under Supervision Of Our Engineer
  • Equipment Condition
    New
  • Voltage
    380V
  • Production Capacity
    99.9%
  • Certification
    ISO;CE;BV
  • Place of Origin
    China
  • Brand Name
    ZK CORP
  • Certification
    ISO, CE
  • Model Number
    lime production plant
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 Days
  • Payment Terms
    L/C, D/A, T/T
  • Supply Ability
    10 per monh

380V Activated Lime Rotary Kiln Easy Maintenance And Low Pollution

Introduction of active lime rotary kiln production line:
Lime production line refers to the whole process equipment line for active lime production. Among all active lime production processes, the rotary kiln production process is the most advanced one. Our production process uses a rotary kiln with a vertical preheater and a vertical cooler to calcine limestone to meet the production requirements of high efficiency, energy saving, environmental protection and high activity.



Main advantages of quicklime plant/lime production line
1. With good quality and high output, it is suitable for large-scale activities and large-scale production of lime production lines.


2. The production is stable, all production adopts negative pressure and airflow, which is more safe.


3. Simple structure, convenient control, convenient operation and maintenance.


4. Fine-grade limestone can be calcined, making full use of mine resources.


5. The heat consumption per unit product is low. It is installed in the superheater of the shaft kiln, and the exhaust gas temperature limestone is used to greatly reduce the fuel consumption.


6. It can make full use of industrial waste gas as the fuel for lime burning and reduce the cost.


7. The kiln head adopts a vertical cooler integrated kiln head cover design. Small construction area, good sealing, effectively avoid unsystematic discharge of hot exhaust gas


ZK is engaged in technology research and development, engineering consulting, equipment debugging, engineering contracting and related technical services in the fields of cement, building materials, mining, environmental protection, metallurgy, chemical equipment manufacturing and other fields. Welcome to visit our company and production workshop, we sincerely look forward to cooperating with you.


We will provide you with the most suitable product at the most reasonable price. If you have any needs, please feel free to contact us, we will reply you as soon as possible.



Specifications:

Capacity 200t/d 225t/d 250t/d 300t/d 400t/d 500t/d 600t/d 800t/d
Preheater Shape Hexagon Hexagon Octagon Octagon Octagon Decagon Dodecagon Dodecagon

Qty. Of

Top Silo

6 6 8 8 8 10 12 12
Qty. Of Hydraulic Pusher 6 6 8 8 8 10 12 12
Preheating Capacity (t) 600 600 800 800 800 1000 1600 1600
Rotary Kiln Size Φ2.8×42m Φ3.0×50m Φ3.2×50m Φ3.3×55m Φ3.6×55m Φ3.8×58m Φ4×60m Φ4.3×56m
Slope 3.50% 3.50% 3.50% 3.50% 3.50% 3.50% 3.50% 3.50%

Rotating Speed

(r/min)

0.3-1.8 0.3-1.8 0.3-1.8 0.3-1.8 0.3-1.8 0.3-1.8 0.3-1.8 0.3-1.8

Calcination Temperature

(℃)

1350 1350 1350 1350 1350 1350 1350 1350
Cooler Type Vertical Vertical Vertical Vertical Vertical Vertical Vertical Vertical
Qty Of Temperature Control Area 3 3 3 3 3 3 3 3

Qty. Of

Wind Tower

4+1 4+1 4+1 4+1 4+1 4+1 4+1 4+1
Size(m) 3.6×3.6 3.6×3.6 3.6×3.6 3.6×3.6 4.1×4.1 4.1×4.1 4.1×4.1 4.7×4.7

Output Temperature

(℃)

≤120 ≤120 ≤120 ≤120 ≤120 ≤120 ≤120 ≤120
Product Thermal Loss(kcal/kg) 5500 5400 5400 5400 5400 5400 5400 5000
Available Fuel Coke oven gas, mixed gas, natural gas, coal powder, low heating value coal gas
