High Efficiency Solid Waste Rotary Kiln Incinerator Low Consumption Simple Maintenance

High Efficiency Solid Waste Rotary Kiln Incinerator Low Consumption Simple Maintenance

  • High Light

    High Efficiency Solid Waste Rotary Kiln

    ,

    sludge waste rotary kiln incinerator

    ,

    municipal waste rotary kiln incinerator

  • Product Name
    Industrial Waste Incineration Complete
  • After Sale Service
    Engineers Available To Service Machinery Overseas
  • Model
    1.6x32m-4.7x72m
  • Material
    Sludge Waste, Municipal Waste
  • Motor Type
    AC Motor
  • History
    60 Years
  • Warranty
    1 Year
  • Voltage
    220v/380v/400v/440v
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    1.6x32m-4.7x72m

High Efficiency Solid Waste Rotary Kiln Incinerator Low Consumption Simple Maintenance

product description

Hazardous waste refers to waste with hazardous properties and characteristics, and has one or more of hazardous properties such as toxic, explosive, flammable, and corrosive. The disposal of hazardous wastes is highly valued at home and abroad. At present, there are two main ways to dispose of hazardous waste: incineration and landfill. Among them, rotary kiln incineration technology is currently widely used hazardous waste treatment technology, and is becoming an important way of harmless treatment of hazardous waste.



【Applicable materials】

Various solid wastes, waste liquids, and waste gases in industrial comprehensive hazardous waste, medical waste, petroleum, chemical, pesticide and other industries.



Advantage

Low cost: high temperature material contacts refractory. Easy to change the lining
The drive mechanism is simple: the drive mechanism is inside the kiln shell. Equipment maintenance is convenient.
To ensure no leakage of harmful gases: good sealing measures and negative pressure in the furnace.
Convenient operation and maintenance: high equipment operation rate. The annual operating rate is generally 90%
Incineration adaptability: solid waste, liquid, colloid and gas can be incinerated at the same time
High heat utilization rate: the material is stirred forward. Three heat transfer methods coexist in one furnace
Combined with patented technology: the traditional two-combustion chamber has evolved into a two-combustion furnace. Improved ash burnout rate. Improve the combustion efficiency of the rotary kiln. At the same time, it has the functions of normal temperature slag discharge, broken slag blocking, and air lock.




Specifications:



Hazardous waste rotary kiln for waste incinerationφ2.6m*13.2 technical parameter.
Inner diameter of shell 2600mm Shell length 13200mm
Downstream arrangement, that is, the direction of material flow is consistent with the direction of smoke flow, the angle of the kiln body is 1.5 degrees.
Variable frequency speed control of rotary kiln 0.1-2.2r/min
Drive mode Single side gear drive
Main Motor 30kw
Kiln temperature:850-1200 degree Surface temperature of kiln shell: 180 degree
Expansion mode Linear free expansion at both ends
Total equipment weight approx. 54.5t
★Customized waste incineration rotary kiln can be provided according to the customers' different industries
