Compact Layout LECA Equipment Low Unit Product Fuel Energy Consumption

Compact Layout LECA Equipment Low Unit Product Fuel Energy Consumption

ceramsite production line

sand production line

Place of Origin:


Brand Name:



CE ISO Certification

Model Number:

Various models

Contact Us
Request A Quote
Product Details
Product Name:
Rotary Lime Kiln,Leca Rotary Kiln
Lead And Zinc Mineral Raw Material
Main Equipment:
LECA Rotary Kiln, Granulator, Rotary Screen Etc
Light Wall Panel Etc
Motor Type:
AC Motor
Spare Parts:
Supply All Using Life
Payment & Shipping Terms
Minimum Order Quantity
1 Set
Packaging Details
Export standard container or as customers' requirements
Delivery Time
30 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100 Set / Sets per Month
Product Description
China Supply Lightweight Expanded Clay Aggregate Plant Leca Equipment
ZK has been developed an energy-saving vertical cooler, granulating technology inside the rotary kiln which is suitable for expended aggregate production line and also developed the disposal method for of dioxin in the waste flue gas of the kiln, all of these solutions have opened up a new process method for the construction of new environmentally-friendly and energy-saving expended aggregate and ceramsite proppant.
Compact Layout LECA Equipment Low Unit Product Fuel Energy Consumption 0
We offer Clay Expanded Aggregate Production, Sludge Expanded Aggregate Production, Fly Ash & Sludge Expanded Aggregate Production by raw material, with different production process. We built our own expanded aggregate calcination experimental pilot platform, ceramsite proppant and expanded aggregated granulation platform and various experimental granulating equipment, which can realize various raw material analysis, calcination experiments, sample making, pilot production before industrial investment, so as to provide the basic industrial data for the later industrialization.
Basic Production Process:

Compact Layout LECA Equipment Low Unit Product Fuel Energy Consumption 1


1. Energy-saving environment friendly
Advanced production process and large capacity for single production line with low heat loss. The advanced bag type dust collector, which is equipped in LECA equipment, keeps exhaust gas below 30mg/Nm3.

2. High degree of automation
Leca production line is fitted with temperature and pressure monitoring instrumentation, operating parameters of the computer display, and is capable of using advanced computer control to achieve automatic operation of the entire system.

3. Lost investment
Based on the features of Light Expanded Clay Aggregate (LECA), double-cylinder insert type rotary kiln controls the preheating and calcination process. The energy-saving vertical preheater is equipped in LECA production line with advanced process, and reasonable design and high level technology.


Compact Layout LECA Equipment Low Unit Product Fuel Energy Consumption 2


No Indicator Unit Value
1 Capacity m3/a 15,000 25,000 35,000 50,000 100,000
2 Product
LECA (Light Expanded Clay Aggregate) m3/a 15,000 25,000 35,000 50,000 100,000
3 Main Fuel and raw material consumption
Clay t/a 8,800 14,700 20,500 29,400 58,800
Shale t/a 8,300 13,900 19,400 27,800 55,600
Coal t/a 1,360 2,270 3,180 4,540 9,080
4 Power Consumption
Fresh Water t/a 1,000 1,500 2,500 3,000 6,000
Power kWh/a 187,500 312,500 875,000 1,250,000 2,500,000
5 Employee Qty Needed a 25 25 23 23 22
