Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life

Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life

  • High Light

    rotary dryer machine

    ,

    rotating drum dryer

  • Product Name
    Mud Drying Machine / Drying Of Sludge Equipment
  • Condition
    New
  • After-sales Service Provided
    Engineers Available To Service Machinery Overseas
  • Warranty
    12 Months
  • Capacity
    1-40(t/h)
  • Material
    Dolomite, Ferrosilicon, Fluorite Powder
  • Motor Type
    AC Motor
  • Spare Parts
    Supply All Using Life
  • Voltage
    220V/380V/440
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    Ø1.0×10m-Ø3.6×36m
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    100 Set / Sets per Month

Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life

High Capacity Drum Coal Drying / Mud Drying Machine / Drying of Sludge Equipment



Coal Drying Machine Introduction:

At present, the direct emission of high temperature flue gas, steam occurs in lots of printing and dyeing factories, power plants, which is a great waste of thermal energy. At the same time, there is a need for the drying of sewage sludge or other materials, which will consume a lot of fuel to supply heat. It will have great significance to reduce the environmental pollution and to alleviate economic pressure of enterprises by making effective use of the waste heat to dry the wet materials. Different factories are with different tail gas temperature, most of them is between 120℃ and 500℃.



Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life 0



Process Flow:

The scheme for maximizing the utilization of system thermal energy can be designed as per different material, waste heat temperature and waste heat flow.

System Advantages:

1. Waste heat utilization, energy saving and environmental protection.
2. No fuel consumption, few power consumption, the original dust removal system can be used to save investment.
3. Obtain raw material locally, additional land is not required.
4. High level of automation, laborsaving.
5. Drying time can be adjusted, and the water content can be controlled after drying.



Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life 1



Technical Data:



specification cylinder Capacity(t/h) motor Power(kw) reducer
D(mm) L(mm) Slope(°) Speed(rpm) model
1212 1200 12000 1.8 5 2-5 Y160LM-6 11 ZQ500
1515 1500 15000 1.8 4.28 4-5 Y160L-6 18.5 ZQ650
1818 1800 18000 1.8 5 6-8 Y200LI-6 22 ZA650
2020 2000 20000 2.0 3.28 7-10 Y200L2-6 30 ZQ650
2222 2200 22000 1.8 2.8 9-14 Y250M-6 45 ZQ650
2424 2400 24000 2.5 2.82 14-16 Y280S-6 55 ZQ750
2626 2600 26000 2.5 2.58 16-18 Y280M-6 75 ZQ850
2828 2800 28000 2.5 2.55 20-22 Y315S-6 90 ZL115
3030 3000 30000 2.5 2.69 22-24 Y315L1-6 132 ZL130
3232 3200 32000 2.5 2.6 24-26 Y315M-4 200 ZSY450
3434 3400 34000 2.5 2.51 26-28 Y315L2-4 315 ZL130
3634 3600 36000 2.5 2.51 30-40 Y315L2-4 315 ZL130
4040 4000 40000 2.5 2.09 40-45 YKK4003-4 400 ZSY630
4242 4200 42000 2.5 2.09 45-46 YKK4005-4 400 ZSY630

Our service: Training & Service
Pre-sale services: enthusiasm
We provide you with the prophase plan, process flow design and manufacturer equipment,
according to your special demand.
Sale services: servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators
and finishing the check and accept together with you.



After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.
In addition, we provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
Welcome to visit our company and workshop, we sincerely look forward to cooperating with you. We will provide you with the most suitable products with the reasonable price.



Drum Mud Coal Drying Equipment Reasonable Structure Long Working Life 2
