Small Fly Ash Industrial Rotary Dryer , Three Cylinder Rotating Drum Dryer

Small Fly Ash Industrial Rotary Dryer , Three Cylinder Rotating Drum Dryer

rotary dryer machine

rotating drum dryer

Place of Origin:


Brand Name:




Model Number:

Fly Ash Rotary Drum Dryer

Contact Us
Request A Quote
Product Details
Product Name:
Small Fly Ash Three Cylinder Rotary Drum Dryer For Sale
Cement,Sand, Slag, Coal
Drum Drying Equipment
5 T
As You Like
Spare Parts:
Supply All Using Life
Payment & Shipping Terms
Minimum Order Quantity
1 Set
Packaging Details
Mini Used Fly Ash Three Cylinder Rotary Drum Dryer Container Transport Packing By Wooden Case Or As Client's Packing Requirement
Delivery Time
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
10 Per Month
Product Description

Small Fly Ash Three Cylinder Rotary Drum Dryer For Sale


Fly Ash Rotary Dryer Introduction:

Fly ash dryer will wet ash from the conveyor into horizontal rotary crushing and cutting machine, in order to prevent the bulk material enters the drying cylinder affects the drying effect, the crushed material is then sent to a drying drum, a lot of copy plate cylinder, arranged as a spiral, by rotating the copy board materials will not stop throw up, Yangsa belt pneumatic cylinder, and the cylinder wall again beating device materials are broken up, the material flow is fully contacted with afferent by induced draft fan system of the heat, heat exchange, evaporation, drying, discharged from the discharge port, discharging dust moisture after dedusting equipment unified dust. Fly ash dryer -- energy-saving, efficient, environmental protection.

Fly ash dryer from ZK CORP can dry the wet fly ash from moisture content 45% to about 8% in large quantity directly.


Small Fly Ash Industrial Rotary Dryer , Three Cylinder Rotating Drum Dryer 0


Fly Ash Rotary Dryer Structure:

Fly ash rotary dryer is mainly compose of driving device, supporting roller, thrust roller, cylinder, kiln inlet, kiln outlet and sealing device.

1. 2-3 supporting points can guarantee the contacting surface between supporting roller and tyre is paralleled with axis line of cylinder during installation.

2. Supporting device is antifriction bearing (occasionally uses slide bearing). This design has simplified the supporting device of supporting roller, and reduced the useless power loss during operation. It has the features like easy operation and maintenance.

3. Suitable shim between tire and shell will ensure the tire ring on the shell tightly to increase the shell strength.

4. The main driving system uses new type AC variable frequency technology. Compared with electromagnetic speed control and DC speed control, that can save energy, have large range & high precision of speed regulation, high efficiency and running smoothly.

5. Radial direction contacting type sealing device is adopted at kiln inlet and outlet. They are perfect suitable for dimension tolerance of cylinder and skewing movement of cylinder. This sealing device’s feature is good performance, longer working life and easy for replacement.



Fly Ash Rotary Dryer Our Advantages​:

1. Low outlet temperature, long lifetime of dust cleaning system;

2. Adopt new type lifting boards, and the output moisture content can be adjusted as customer's demand;

3. High drying efficiency, big capacity, high running rate;

4. Broad fuel choice: coal, diesel, natural gas, waste wood, etc.


Small Fly Ash Industrial Rotary Dryer , Three Cylinder Rotating Drum Dryer 1


Fly Ash Rotary Dryer Specifications:


Ø1.0×10m 1-2 5 ZQ400 YCT200-4B 7.5
Ø1.2×12m 2-3 5 ZQ500 YCT225-4A 11
Ø1.5×15m 3-5 5 ZQ500 YCT225-4B 15
Ø1.8×18m 4-6 4 ZQ750 YCT250-4B 22
Ø2.0×20m 7-9 3.5 ZQ750 YCT280-4A 30
Ø2.2×22m 8-10 3.5 ZQ850 YCT315-4A 37
Ø2.4×24m 12-15 3.5 ZQ850 YCT315-4B 45
Ø2.8×28m 16-22 3.5 ZS145 YCT355-4A 55
Ø3.0×30m 20-25 3.5 ZS165 YCT355-4B 75
Ø3.2×32m 28-32 3.5 ZL130 YCT355-4C 90
Ø3.6×36m 38-40 3.5 ZL130 YVF2-315L2-6 132

Our service:

Training & Service

Pre-sale services: enthusiasm

We provide you with the prophase plan, process flow design and manufacturer equipment, according to your special demand.


Sale services: servant

Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.


After-sale services: faithfulness

To establish long term friendship, we will regularly pay return visit to customers.

In addition, we provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.


Welcome to visit our company and workshop, we sincerely look forward to cooperating with you. We will provide you with the most suitable products with the reasonable price.


Small Fly Ash Industrial Rotary Dryer , Three Cylinder Rotating Drum Dryer 2
