Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life

Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life

  • High Light

    rotary dryer machine

    ,

    rotary drying equipment

  • Product Name
    High Capacity Drum Coal Drying, Coal Drying Machine
  • Condition
    New
  • After-sales Service Provided
    Engineers Available To Service Machinery Overseas
  • Warranty
    12 Months
  • Capacity
    1-40(t/h)
  • Material
    Cement,Sand, Slag, Coal, Limestone
  • Motor Type
    AC Motor
  • Spare Parts
    Supply All Using Life
  • Voltage
    220V/380V/440
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    Ø1.0×10m-Ø3.6×36m
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    80 Set / Sets per Month

Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life

Small Industrial Rotary Dryer / Dryers for Limestone Material





Small Industrial Rotary Dryer Introduction:
The material inside the rotary dryer has heat exchange with the high temperature flue gas through shell rotating and material lifting by lifter. The rotary dryer has many good characters like: high efficiency, big capacity, high running rate, saving energy, easy for maintenance, long working life. Variety angle of the lifter will increase the heating exchange rate and short drying time. That is widely used for drying lay, slag, fly ash & etc.

Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life 0



Performance Characteristics:
1. The operation parameters can be changed according to the different material properties, the material in the dryer cylinder can form stable material curtain, to make the heat exchange more fully;


2. New feeding and discharging device, put an end to the phenomenon of the plug in feeding, incontinuity, nonuniform and material return of traditional dryer, and reduce the load of dust removal system;


3. Counterflow drying method, it can obtain higher evaporation intensity; downstream drying method and indirect drying method are suitable for drying materials which are sensitive to temperature;


4. Fuel can be diesel oil, heavy oil, and natural gas, gas, coal, electricity and biomass particles for environmental protection;


5. It makes use of waste to produce useful product, like fertilizer, concrete aggregate etc. That is to say, this machine is environmental friendly.


Advantages of Cement Dryer:
1. High drying efficiency, big capacity, high running rate


2. Compact structure, operation stable, easy maintenance


Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life 1


Specifications:


MODEL CAPACITY(t/h) SLOPE(%) GEARBOX MOTOR POWER(kW)
Ø1.0×10m 1-2 5 ZQ400 YCT200-4B 7.5
Ø1.2×12m 2-3 5 ZQ500 YCT225-4A 11
Ø1.5×15m 3-5 5 ZQ500 YCT225-4B 15
Ø1.8×18m 4-6 4 ZQ750 YCT250-4B 22
Ø2.0×20m 7-9 3.5 ZQ750 YCT280-4A 30
Ø2.2×22m 8-10 3.5 ZQ850 YCT315-4A 37
Ø2.4×24m 12-15 3.5 ZQ850 YCT315-4B 45
Ø2.8×28m 16-22 3.5 ZS145 YCT355-4A 55
Ø3.0×30m 20-25 3.5 ZS165 YCT355-4B 75
Ø3.2×32m 28-32 3.5 ZL130 YCT355-4C 90
Ø3.6×36m 38-40 3.5 ZL130 YVF2-315L2-6 132

Industrial Small Rotary Dryer Energy Saving High Running Rate Long Service Life 2
