Lime Dust Collection Equipment , Cyclone Dust Collection System Low Capital Cost
Product Details:
| Place of Origin: | China |
| Brand Name: | ZK |
| Certification: | CE ISO Certification |
| Model Number: | XD-Ⅱ-0.5-XD-Ⅱ-35 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export standard container or as customers' requirements |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 Set / Sets per Month |
|
Detail Information |
|||
| Product Name: | Lime Dust Collection System, Cyclone Dust Collector | Model: | XD-Ⅱ-0.5-XD-Ⅱ-35 |
|---|---|---|---|
| Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Warranty: | 12 Months | Volume: | 1500-105000(m3/h) |
| Application: | Mining, Metallurgy, Refractory, Coal, Chemical | Motor Type: | AC Motor |
| Spare Parts: | Supply All Using Life | ||
| High Light: | bag dust collection system,industrial cyclone dust collector |
||
Product Description
Lime Dust Collection System / Cyclone Dust Collector for Sale
Cyclone Dust Collector Introduction:
Cyclone Collector are often employed as an Initial Stage Collector to lighten heavy dusts loads before being sent to a Primary Stage Fabric Collector. By removing coarse particles from the gas stream, and allowing later stage Fabric Collectors to solely remove finer particles, these collectors increase the efficiency and service life of Fabric Collectors (Baghouses) and their Filters. Thus protecting your larger and most costly investment from unnecessary wear and tear.Cyclone Separator or Dust Collector Price for Boiler Cyclone Collector are often employed as an Initial Stage Collector to lighten heavy dusts loads before being sent to a Primary Stage Fabric Collector. By removing coarse particles from the gas stream, and allowing later stage Fabric Collectors to solely remove finer particles, these collectors increase the efficiency and service life of Fabric Collectors (Baghouses) and their Filters. Thus protecting your larger and most costly investment from unnecessary wear and tear.
Cyclone Dust Collector Advantages:
1. Low capital cost.
2. Ability to operate at high temperatures.
3. Can handle liquid mists or dry materials.
4. Low maintenance requirements (no moving parts).
5. Small footprint - requires relatively small space.
Cyclone Dust Collector Specifications:
| Specification | XD-Ⅱ-0.5 | XD-Ⅱ-1 | XD-Ⅱ-2 | XD-Ⅱ-4 | XD-Ⅱ-6 | XD-Ⅱ-10 | XD-Ⅱ-20 | XD-Ⅱ-35 |
| Boiler(t/h) | 0.5 | 1 | 2 | 4 | 6 | 10 | 20 | 35 |
| Exhaust Gas Volume (m3/h) | 1500 | 3000 | 6000 | 12000 | 18000 | 30000 | 60000 | 105000 |
| Collection efficiency(%) | ＞95 | |||||||
| Pressure drop(Pa) | ＜900 | |||||||
| Cut diameter | 3.05 | |||||||
| Weight | 310 | 570 | 960 | 1900 | 2910 | 6100 | 11750 | 20300 |
The most important parameters of a cyclone as for any separating device are its collecting efficiency and the pressure drop across the unit. The collecting efficiency of a cyclone is defined as its ability to capture and retain dust particles whereas the pressure drop is the amount of power that the unit needs to do so.
