Coal Classifying Slurry 48t/H Vibrating Screen Machine

Coal Classifying Slurry 48t/H Vibrating Screen Machine

  • High Light

    48t/H Vibrating Screen Machine

    ,

    Slurry Vibrating Screen Machine

  • Product Name
    Coal Classifying Vibrating Screen Machine
  • Screen Layer
    2-4
  • Screen Square
    4.5-8.1 (m2)
  • Capacity
    15-48(t/h)
  • Material
    Slurry, Coal, Ore Dressing
  • Shipping Port
    Shanghai, Qingdao, Tianjin
  • Warranty
    One Year
  • Motor Type
    AC Motor
  • Voltage
    Local Voltage
  • Business Scope
    Design, Manufacturer, Onsite Guidance
  • Place of Origin
    China
  • Brand Name
    ZK
  • Certification
    CE ISO Certification
  • Model Number
    GPS-4,GPS-8
  • Minimum Order Quantity
    1 set
  • Packaging Details
    Export standard container or as customers' requirements
  • Delivery Time
    30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    50 Set / Sets per Month

Coal Classifying Slurry 48t/H Vibrating Screen Machine

Coal Classifying Vibrating Screen Machine Compact Layout Reliable Performance



Introduction

High frequency screen is a kind of feeding and classifying screen that divided into upper way, medium way and lower way, which is a high efficient screen used to screening andclassifying of small size materials. Each way can complete feeding, screening and discharging processes independently. The screen device is assembled by three overlapped screens with different screen sizes. It is used very widely in many kinds of dressing plants, such as ironore, titanium iron ore, tungsten ore, tin ore, tantalum ore,ect.



Coal Classifying Slurry 48t/H Vibrating Screen Machine 0



Our Advantages​:
1. Sieve machine design, ingenious and easy to assemble, one person can operate the screening machine.
2. Independent and other related brand manufacturers, compared with a larger screen area and high efficiency of processing capacity.
3. Unique screen structure design, convenient and fast change screen (only 3 to 5 minutes), in addition, this design allows the use of a variety of screen (nylon, special dragon, PP nets).
4. The parent network to fully support the fine mesh, so fine mesh scored a longer life, and reduce the supplies of fine mesh, the production process and the long time can reduce a lot of cost.



Coal Classifying Slurry 48t/H Vibrating Screen Machine 1





Working Principle:

The straight shaking movement is realizedby two unbalanced gravities of high frequency screen. Two motors drive upperand lower shaft separately do reversed rotation movements. The existing forces,produced by synchronous opposite rotation and formed 30°with screen face, are overlapped. At the same, existing forces inother direction are offset. Then the single direction existing force is formedso that the screen shaking reciprocally along straight line. Because the screenis shaking along overlapped exciting force in high frequency and no shaking inother direction, the screen is working stably.





Specifications:



Model

Screen square

(m2)

Thickness of input material (%) Capacity (t/h) Power (kw)
GPS-4 4.5 30%-40% 15-25 0.72
GPS-5 5.2 30%-40% 20-30 1.1
GPS-6 6 30%-40% 24-36 1.5
GPS-8 8.1 30%-40% 32-48 2.2
