China Active Lime Production Line manufacturer

Highly Efficient Cement Rotary Kiln Energy Saving With ISO CE Approved

Product Details:
Place of Origin: China
Brand Name: ZK
Certification: CE ISO Certification
Model Number: According to different models
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Export standard container or as customers' requirements
Delivery Time: 30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Set / Sets per Month
Contact Now

Detail Information

Model: Φ1.6x32 - Φ4.7x72 (m) Capacity: 2 - 104 (t/h)
Material: Dolomite, Limestone, Bauxite, Etc. Motor Type: AC Motor
Application: Cement, Lime, Magnesium, Zinc Oxide, LECA, Oil Fracturing Proppant, Etc. Product Name: Cement Rotary Kiln
After-sales Service Provided: Engineers Available To Service Machinery Overseas Warranty: 12 Months
High Light:

calcination rotary kiln

,

vertical shaft kiln

Product Description

High Efficient Cement Rotary Kiln With ISO CE Approved Sale



Rotary Kiln Introduction:

Rotary Kiln belongs to building material equipment, according to different materials, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln. Cement kiln is used for making cement clinker and there are dry and wet methods to make cement clinker. Metallurgy chemical kiln is widely used for magnetic roasting of poor iron ore and oxidizing roasting of chrome and nickel in the steel factory; backing high-alumina mine in the refractory material factory; baking chamotte and alumina in the aluminum factory and baking chrome ore and chrome powder in the chemical plant. The Lime Kiln is used for roasting active lime in steel works and ferroalloy plants and light roasting dolomite.



Highly Efficient Cement Rotary Kiln Energy Saving With ISO CE Approved



Wide Application of Rotary Kiln:

Rotary kiln refers to rotary calcining kiln, mainly used for calcining calcium aluminate, limestone, bauxite, kaolin clay, gypsum etc., which is widely used in the fields of building materials, metallurgy, chemical industry, environmental protection, etc.



Highly Efficient Cement Rotary Kiln Energy Saving With ISO CE Approved



OUR ADVANTAGE

1. New type technology is adopted by main driving system. Compared with traditional magnetic and DC speed regulation, its main driving system has the advantages like energy saving, environmental, wide speeding adjusting range, high performance and stable operation.



2. After the welding of bases for supporting devices of supporting roller and catching roller, vibration aging treatment should be applied for remove the welding stress. Then, use vertical lathe and boring-milling machine for integration fabrication. This process can guarantee the requirement of fabrication precision and dimension & location tolerance. Installation accuracy of rotary kiln is obviously improved.



3. This process can guarantee the requirement of fabrication precision and dimension & location tolerance. Installation accuracy of rotary kiln is obviously improved.



4. Temperature measuring point is reserved at bearing base of supporting roller. It is mainly used for automation detection of kiln operation status by insert the measuring device.



Highly Efficient Cement Rotary Kiln Energy Saving With ISO CE Approved



Structure:

1. Support device: advanced shaft structure, automatic temperature measuring device and electrical heating.

2. Catch wheel: including two kinds of mechanical wheel and hydraulic pressure.

3. Gears: single or double. Control the rotating speed by variable motor, DE machine and frequency variable motor. Be reliable, energy saving and efficient.



4. Cylinder tyre bolster: lower bolster has three types: fixed, zoom and floating. The structure is simple. Replacement is convenient and won't hurt cylinder.

5. Sealing equipment: there are many kinds for choice according to kiln models, including air cylinder edge sealing, spring edge sealing, graphite block sealing and combination for above. The feather is adaptive for cylinder rotating and swing. And sealing effect is very good.

6. Kiln head hood: including stationary type and flexible type.



Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Rotary Kiln:http://www.inczk.com/Calcining.html
Cement Mill: http://www.inczk.com/Grinding/44.html
Dust Collector: http://www.inczk.com/Dust.html
Preheater: http://www.inczk.com/Calcining/40.html
Rotary Dryer: http://www.inczk.com/Drying/28.html
Raw Mill: http://www.inczk.com/Grinding/42.html
Trommel Screen:http://www.inczk.com/Screening/5.html
Rotary cooler:http://www.inczk.com/Other/41.html



Specifications:

Spec Output(t/h) Rev(rpm) Pedestal Number Reducer Electricmotor Powe(kW)
Model
Ф1.6x32m 2.0 0.58-2.85 3 ZQ75-50 YCT250-4A 18.5
Ф1.6/1.9x36m 2.5-3.0 0.53-1.59 3 ZQ110-7 YCT250-4B 22
Ф1.9x39m 3.0-3.4 0.53-1.59 3 ZQ125-7 YCT315-4A 37
Ф2.2x45m 4.0-5.0 0.21-1.64 3 hostZS125-5 hostYCT315-4B 45
assistZQ40-40 assistY112M-4 4
Ф3.2x50m 1000 0.79-3.94 3 hostNZS955-28VBR hostZSN4-280-21B 160
assistZL50-9-2 assistY180L-6 15
Ф3.2x64m 8.0-10.0 0.40-1.50 4 hostZL130-16 hostZSN-280-11B 190
assistZL50-10 assistY180L-4 22
Ф3.2x118m 17.0 0.29-1.46 6 hostJH500C-SW-71 hostZ4-250-31 110
assistZL50-8-1 assistY160L-6 11
Ф3.3x50m 1000 0.36-3.57 3 hostNZS995-40-VBL hostZSN4-280-21B 160
assist NZS352-31.5 assistY160M-4 11
Ф3.8x58m 20.8 0.4-1.5 3 hostZSY500-40 hostzsn-315-072 250
assistZL50-14 assisty180L-4 22
Ф4.0x60m 25 0.4-1.5 3 hostZSY630-35.5 hostZSN4-355-092 315
assistZL65-16 assistY200L-4 30
Ф4.0x80m 29.17 0316-1.528 4 hostJH560C-SW-71 hostZSN4-280-11B 160
assistZL50-9-1 assistY180L-6 15
Ф4.0/3.5/4.0x150m 30.4 0.34-1.71 6 hostJH560C-SW-56-1/2 hostZSN4-280-11B 2X125
assistZL50-10-1/2 assistY160L-6 2X11
Ф4.0x150m 33.3 0.51-1.53 6 hostJH560C-SW-63-1/2 hostZSN4-280-11B 2X125
assistZL60-12-1/2 assistY160L-6 2X11
Ф4.0x150m 30.0-34.0 0.40-1.59 6 hostJH800C-SW-90 hostZSN4-355-092 280
assistJH280-SW-40 assistY200L-4 30
Ф4.7x72m 4000 0.35-3.50 3 hostZSY710-28-V hostZ4-400-32 550
assistZL60-7-2 assistY200L-4 30


Remark:According to the requirement, the kiln length and driving system can be revised.
★ means the rotary kiln match with vertical pre-heater
Main spare parts is 1, sealing plate, 2. Oil sealing, 3. Nylon pin 4, Rubber block 5, Kiln head back plate.
