China Active Lime Production Line manufacturer

Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair

Product Details:
Place of Origin: CHINA
Brand Name: ZK CORP
Certification: ISO,CE
Model Number: Vertical Shaft Cement Kiln Plant
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: MEET THE SHIPPMENT REQUIRMENTS
Delivery Time: 30DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 PER MONTH
Contact Now

Detail Information

Capacity: 50 - 500 (t/d) Fuel: Mixed Fuel, Gas, Coal Powder
Limestone Size: 30~60 (mm) / 40~80 (mm) Application: Lime Production Plant
Service: Design, Manufacturing, Sales Etc Limestone Size (mm): 30~60/40~80
Heat Consumption (kJ/kg): <4600 CaO (%): >90
Activity (mL): >300 Equipment Condition: New
High Light:

calcium carbonate production line

,

coal production line

Product Description

Good Price Cement Turnkey Project Vertical Shaft Cement Kiln Plant

Description of Lime Vertical / Shaft Kiln:

Vertical Shaft Kiln to building material equipment, is the main equipment for sintering cement clinker in cement production plant, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.
1. Cement Vertical Shaft Kiln is used for making of cement clinker and there are dry and wet methods to make cement.
2. Metallurgy chemical Vertical Shaft Kiln is used in metallurgy industry and ironworks for lean iron ore, chromium ore and ferronickel ore calcimine.
3. Lime Vertical Shaft Kiln is used in the most important equipment in lime production line.

Advantages Of Ours Kiln:

1. Solid structure, stable performance, high production efficiency.
2. Convenient operation, easy repair. Its energy consumption is reduced by 15% compared with the same kind of products.
3. The duration is far more than the same kind of products.
4. The stable performance and advanced structure have greatly improved its preheating effects.
5. Advanced processing technology, high cost performance ratio.
6. It can roast cement and metal ore with controllable temperature and wide application ranges.



Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair 0



Parameter



Technical Parameters Of Vertical Klin (Mixed Fuel)
Capacity
(t/d)
Effective Volume
(m3)
Effective Height
(m)
Effective Section
Dia. (m)
Limestone Size
(mm)
Heat Consumption
(kJ/kg)
CaO
(%)
Activity
(mL)
100 98 20 Ø2.5 30~60/40~80 <4600 >90 >300
120 141 20 Ø3.0 30~60/40~80 <4600 >90 >300
150 202 21 Ø3.5 30~60/40~80 <4500 >90 >300
200 301 24 Ø4.0 30~60/40~80 <4500 >90 >300
300 397 25 Ø4.5 30~60/40~80 <4400 >90 >300
400 491 25 Ø5.0 30~60/40~80 <4200 >90 >300
500 735 26 Ø6.0 30~60/40~80 <4200 >90 >300
Remarks: All above data are for reference only.
Technical Parameters Of Vertical Lime Kiln (Fuel: Gas)
Capacity
(t/d)
Effective Volume
(m3)
Effective Height
(m)
Effective Section
Dia. (m)
Limestone Size
(mm)
Heat Consumption
(kJ/kg)
CaO
(%)
Activity
(mL)
50 70 20 Ø2.0 30~60/40~80 <4600 >90 >300
70 80 20 Ø2.5 30~60/40~80 <4600 >90 >300
80 100 20 Ø2.5 30~60/40~80 <4500 >90 >300
100 120 20 Ø2.7 30~60/40~80 <4500 >90 >300
120 140 20 Ø3.0 30~60/40~80 <4400 >90 >300
130 150 21 Ø3.0 30~60/40~80 <4200 >90 >300
150 200 20 2.5×4.5 30~60/40~80 <4200 >90 >300
Remarks: Above data are for reference only, and suitable for Vertical Kiln which use low heat fuel. Utilization coefficient of Vertical Kiln which use high heat fuel is higher.
