ISO Approve Vertical Grinding Mill , Vertical Roller Mill For Cement



Introduction of Cement vertical mill

Cement vertical mill is a new type of high efficiency, energy conservation and environmental protection of grinding equipment, it is mainly used for grinding raw meal, clinker, which is used in cement grinding station and cement production line. Also can used for grinding slag, iron ore, limestone, coal powder, coke powder, coal gangue, fly ash, volcanic ash, gypsum, calcite, pyrophyllite, quartz, clay, sandstone, bauxite and other processing industry related to metal and non-metal mine.



ISO Approve Vertical Grinding Mill , Vertical Roller Mill For Cement 0

It gathers grinding, drying and powder selecting as a whole, with high grinding efficiency and high drying capacity ( the maximum material moisture can be up to 20% ). The vertical mill adopts dynamic powder selecting device, which comes with high powder-selecting efficiency and convenient adjustment of fineness.

The material is grinded between rotor and ring as the rotor is rotating. The ground powder will be blown into the classifier; the fine powder will be collected by the collector while the coarse powder will be regrinded to the required size.



ISO Approve Vertical Grinding Mill , Vertical Roller Mill For Cement 1

Engineering for equipment and technology, manufacturing, installation and commissioning as well as the supply of the spare parts and the training service can be offered by China ZK for customers.



Advantages of Cement Vertical Mill



1. ZK series cement vertical mill is developed with the features of high efficiency, energy-saving and environmental protection which is achieved after exchanging ideas with senior experts from home and abroad and making improvements based on same sector experience in the past years.

2. ZK technical center can help our client to finish feasibility study, environment impact assessment and safety assessment and also provides turnkey service with high efficiency.

3. ZK has its own various processing equipment and takes strict control measures on product quality, which results in fast delivery within a short time. Besides, ZK can guarantee completion and operation as scheduled with its strong service team for installation and after–sales service.

Parameter of Cement Vertical Mill

Model Grinding Table Diameter
(mm)
Roller Diameter
(mm)
Roller Number
(n)
Motor
(kW)
Output
(t/h)
GRMR22.30 2200 1400 3 550 70
GRMR26.30 2600 1600 3 790 100
GRMR28.30 2800 1750 3 900 115
GRMR30.30 3000 1700 3 1000 120
GRMR32.30 3200 1500 3 1400 160
GRMR34.30 3400 1500 3 1600 180
GRMR36.41 3600 1600 4 1800 200
GRMR38.41 3800 1700 4 1900 230
GRMR40.41 4000 1800 4 2240 260
GRMR43.41 4300 1900 4 2500 310
GRMR46.41 4600 2060 4 3150 350
GRMR48.41 4800 2240 4 3350 390
GRMR50.41 5000 2360 4 3500 420
GRMR53.41 5300 2500 4 3800 470
GRMR56.41 5600 2600 4 4500 540
GRMR59.61 5900 2600 6 5000 610
GRMR63.61 6300 2700 6 6000 720


Note: mill spectral pattern benchmark

  1. Material medium friction (MF)=0.9~1.0;
  2. Material moisture max 7%;
  3. Refined powder granularity 80μmR 12~15%;
  4. Refined powder moisture 0.5~1.0%;
  5. The concrete mill installed power and technology parameter will be adjusted appropritely basing on the actual material property and requirements of owner;
  6. The above specification also applies to limestone powder mill, and the concrete type selection shall be decided according to material property.
